ILME CNEM16T — 16‑Pin Male Insert (CNE Series)

Overview

The ILME CNEM16T is a heavy-duty male insert (plug) module designed for ILME’s modular rectangular connector system (CNE / C‑Type family). It offers screw‑type terminations, accommodating 10 signal contacts plus protective earth (PE). When combined with compatible hoods and bases, it forms a rugged, sealed connector suitable for industrial and automation applications.

Key Features & Specifications

• Contact Configuration: 16 signal contacts + PE (protective earth)
• Current Rating: 16 A per contact
• Voltage Rating: 500 V (some listings mention up to 600 V)
• Termination Style: Screw terminals, with wire protection features
• Housing Material: Glass‑reinforced thermoplastic, self‑extinguishing per UL 94 V‑0
• Contact Plating: Silver plated for corrosion resistance and better conductivity
• Operating Temperature: –40 °C to +125 °C
• Wire Size Range: ~0.5 ... 2.5 mm² (AWG ~14 to ~20)
• Insertion / Module Size: Size 77 × 27 mm (“77.27” modular dimension)
• Ingress / Protection: The insert module itself is typically rated for IP20 in unmated state; sealing is achieved by mating housings/hoods/bases in the full assembly
• Mechanical Durability: Designed for repeated mating cycles when used within proper connector assemblies

Benefits & Applications

• Enables robust field wiring with secure screw‑terminal connections
• Ideal for industrial automation, machine control, and equipment interconnections
• Part of ILME’s modular system, allowing flexibility in choosing hoods, bases, and configurations
• Serves as the male “plug” half when paired with matching female insert and housing
• Silver plating and durable housing materials help maintain performance in demanding environments

Typical Specification Table

Ordering & Compatibility Notes

• The CNEM16T is the male insert only — it does not include the housing, hood, or base.
• To build a full connector, you must pair this insert with a matching female insert, plus suitable hoods / bases / gaskets of the same module size.
• Ensure that the mating housings / covers provide the necessary sealing (IP rating) when assembled.
• Use proper torque values on the screw terminations and follow wiring best practices to avoid mechanical or electrical failures.
• This part is commonly stocked by industrial electrical component distributors. For example, the CNE family is well represented in heavy-duty connector product lines.
• Confirm in your region whether the 500 V or 600 V version is the correct spec for your application, as some datasheets list 600 V.
