Faber-com MAPS Voltage (Danfoss) Joystick
$780.00
TYPE
LEVER
1
Product Details
Faber‑com MAPS Joystick — Voltage / Danfoss Output
Product Overview
The MAPS joystick from Faber‑com is a single‑axis, electronic joystick providing a voltage (signal) output compatible with Danfoss proportional systems. It is part of the MAP / MAS joystick family, where “MAPS” generally refers to a version with voltage / signal (rather than pure PWM or other output types). The joystick is engineered to directly interface with proportional valves or control electronics without needing a separate driver card.
Key Features & Capabilities
- Single Voltage Output
The MAPS joystick delivers a proportional voltage output signal. Typical selectable ranges include:
– 0 to 5 V
– 0 to 10 V
– 5 → 0 → 5 V (i.e. centered output)
– 0.5 → 2.5 → 4.5 V
Custom ranges within 0–10 V are also supported.
- Ratiometric Output Option
Supports ratiometric signaling (25 %, 50 %, 75 % of supply voltage) to ensure compatibility with Danfoss valve inputs.
- Hall‑Effect Sensing
Joystick position is detected using redundant Hall effect sensors that measure the magnetic field of a permanent magnet—this non‑contact sensing method avoids mechanical wear and improves durability.
- Direct Valve Control
The joystick is capable of directly driving PWM or ratiometric solenoid valves, eliminating the need for auxiliary driver circuits.
- Adjustable Parameters
Onboard parameters that can typically be configured include:
• Output curve shape (linear or parabolic)
• Signal ramps (rise/fall times up to 25 s in 0.1 s steps)
• Deadband settings
• Blocking or limiting one or both sides of output
• Speed reduction function
• Digital directional outputs (FAULT, etc.)
• Optional friction or spring‑return lever styles
- Configuration & Programming
All working parameters are programmable via a serial interface using Faber‑com’s configuration software (e.g. SepSim) and a serial adapter (e.g. AISR).
A programming port (often M8) is provided.
- Protection & Reliability
The internal electronics include protection against reverse polarity, short circuits on outputs, and stable feedback control to maintain output consistency despite supply fluctuations.
- Mechanical / Electrical Specs
• Supply Voltage: 10 to 30 VDC
• Operating Temperature Range: –40 °C to +70 °C
• Connector: 20 cm lead with Deutsch connector (e.g. DT04‑8 or variant)
• Working Angle (lever deflection): Typically around ±26°
• LED Indicator: Multicolor LED beneath panel indicates power and fault status
• Ingress Protection: Designed for robust, industrial environments
The MAPS joystick delivers a proportional voltage output signal. Typical selectable ranges include:
– 0 to 5 V
– 0 to 10 V
– 5 → 0 → 5 V (i.e. centered output)
– 0.5 → 2.5 → 4.5 V
Custom ranges within 0–10 V are also supported.
Supports ratiometric signaling (25 %, 50 %, 75 % of supply voltage) to ensure compatibility with Danfoss valve inputs.
Joystick position is detected using redundant Hall effect sensors that measure the magnetic field of a permanent magnet—this non‑contact sensing method avoids mechanical wear and improves durability.
The joystick is capable of directly driving PWM or ratiometric solenoid valves, eliminating the need for auxiliary driver circuits.
Onboard parameters that can typically be configured include:
• Output curve shape (linear or parabolic)
• Signal ramps (rise/fall times up to 25 s in 0.1 s steps)
• Deadband settings
• Blocking or limiting one or both sides of output
• Speed reduction function
• Digital directional outputs (FAULT, etc.)
• Optional friction or spring‑return lever styles
All working parameters are programmable via a serial interface using Faber‑com’s configuration software (e.g. SepSim) and a serial adapter (e.g. AISR).
A programming port (often M8) is provided.
The internal electronics include protection against reverse polarity, short circuits on outputs, and stable feedback control to maintain output consistency despite supply fluctuations.
• Supply Voltage: 10 to 30 VDC
• Operating Temperature Range: –40 °C to +70 °C
• Connector: 20 cm lead with Deutsch connector (e.g. DT04‑8 or variant)
• Working Angle (lever deflection): Typically around ±26°
• LED Indicator: Multicolor LED beneath panel indicates power and fault status
• Ingress Protection: Designed for robust, industrial environments
Use Cases & Applications
- Control panels in mobile or industrial hydraulic systems
- Direct control of Danfoss proportional valves via voltage or ratiometric signals
- Marine, off‑road, or rugged environments where a signal joystick output is preferred
- Situations where eliminating external driver modules is advantageous for simplicity, space, or reliability
